11
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
MOUNT THE BANDSAW ON TO THE STAND
1. Lift the bandsaw on to the stand,
making sure the motor is on the
same side as the assisted support
legs.
2. Use the 4 x M8 x 45 bolts, washers
and nuts supplied to attach the
band saw to the stand.
• Put the bolts through the base
of the saw from above.
• Install the washers and nuts on
the underside of the stand and tighten to secure.
3. Tighten all bolts and nuts on the saw and stand.
INSTALL THE SAW TABLE
1. Remove the two screws, knurled
nuts and U shaped packer from
the work table.
2. Guide the work table past the
blade and place on the table
trunnion. Position the table insert
on the work table correctly.
WARNING: WHEN YOU MOUNT THE BAND SAW ON TO THE STAND WE
RECOMMEND THAT YOU GET HELP BECAUSE OF THE WEIGHT OF THE
BANDSAW.
