14
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
USING THE FENCE
• The rip fence can be used on
either side of the blade.The
scale indicates the distance
from the saw blade to the
fence.
1. Place the fence over the table
and into the required position and
press down the locking clamp to
hold the fence in position.
USING THE PUSH STICK
1. The push stick serves as an
extension of the operators hand
as protection against accidentally
touching the saw blade.
2. The push stick should be used if
the distance between the blade
and rip fence is less than approx.
150mm.
3. Always replace the push stick if
lost or damaged.
4. To reduce the chance of loss
always store the push stick on the
hanging bolt on the side of the
saw (M6 x 35 bolt & locking nut).
Warning: ALWAYS USE A PUSH STICK WHEN STRAIGHT CUTTING SMALL
WORK PIECES USING THE FENCE.
