SPECIFICATIONS
Model CBS250C
Power 500W, 230V/50Hz, 5A
Blade T10 Carbon Tool Steel, 6 p.t.i
Blade Speed 467 rpm
Blade Length 1,712 mm
Blade Width 3.5-12 mm
Max Width of Cut (Throat Width) 245 mm
Max Depth of Cut 115 mm @ 90° / 65 mm @ 45°
Table Size 302 x 304 mm
Table Height on Stand 884 mm
Table Tilt Angle 90° to 45°
Dust Extraction Outlet 35 mm (inside) / 40 mm (outside)
IP Rating IP20
Duty Cycle Classification S1 (Continuous)
Sound Pressure Level 82.3 dB LpA
Sound Power Level 94.4 dB LWA
Sound Uncertainty Factor (K) 3 dB
Dimensions (L x W x H) 730mm x 550mm x 1310mm
We ig h t ( B an d sa w an d St a nd ) 2 9 .6 kg
