3. Attach the work table with 3 x M6
x 16 bolts, washers and nuts.
4. Attach the two screws, knurled
nuts and U shaped packer that
were removed in step one and
fasten
• ALWAYS replace the table insert
when worn.
FIT THE RIP FENCE TO THE TABLE
1. Loosen the locking clamp.
2. Slide the rip fence onto the table.
3. Tighten the locking clamp to
secure the rip fence in place.
CONNECTING TO A DUST COLLECTOR
This bandsaw is fitted with a dust port
to enable connection to a dust
collector.
• Outside Diameter 40 mm
• Inside Diameter 35 mm
The bandsaw is now ready to use.
