29
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
063 Guide Block 096 Adjusting Knob Cover
064 Plug & Power Cable 097 Upper Blade Guide
065 Bolt M6 x 20 098 Upper Guide Pin
066 Flat Washer 8 099 Fixing Rod
067 Bolt M6 x 16 100 Screw M6 x 12
068 Big Flat Washer 6 101 Screw ST4.2 x 13
069 Bench Angle Gauge 102 Upper Blade Guide Seat
070 Lock Plate 103 Locknut
071 Lock Knob 104 U Shaped Packer
072 Bolt M6 x 35 105 Work Table
073 Locknut M6 106 Bolt M6 x 20
074 Blade Guide 107 Table Insert
075 Motor Pulley 108 Machine Body Weldment
076 Screw M6 x 6 109 Rip Fence Locker
077 Spring Washer 6 110 Pin 3 x 16
078 Motor Connecting Plate 111 Connecting Bushing
079 Flat Key 5 x 25 112 Flat Washer 10
080 Bolt M8 x 20 113 Rip Fence Holder
081 Motor 114 Stop Block
082 Bearing 625-2Z 115 Clamping Block
083 Bearing Shaft 116 Bolt M6 x 10
084 Lower Guide Pin 117 Rip Fence
085 Lower Blade Guide 118 Rip Fence Spring
086 Screw ST3.5 x 9.5 119 Clamping Press Plate
087 Top Coverplate for Upper Blade
Guide
120 Clamping Screw Rod
088 Rack 121 Cable Gland Strain Relief
Connector
089 Upper Blade Guide 122 Lower Pulley Shaft
090 Sliding Plate 123 Bolt M6 x 20
091 Pin 2.5 x 12 124 Suction Connector
092 Gear 125 Lock Washer 5
093 Gear Shaft 126 Hood
094 Adjusting Knob Seat 127 Upper Microswitch Cable
095 Locknut M8 128 Lower Microswitch Cable
To Next Page
