CONTENTS - STAND
Make sure that all parts are un-damaged and are present. If any parts are
missing or damaged please contact your CLARKE dealer immediately.
The following loose components are supplied with the stand assembly.
ITEM DESCRIPTION ITEM DESCRIPTION
1 2 x Long Beam - 400mm 6 2 x Assisted Support Leg -
190mm x 260mm
2 4 x Stand Legs - 560mm 7 24 x M8 x 16 Bolt, Washer & Nut
4 x M6 x 16 Bolt, Washer & Nut
4 x M8 x 45 Bolt, Washer & Nut
3 2 x Short Beam - 230mm 8 Allen Key (5mm)
4 4 x Rubber Feet 9 2 x Short Support Plate - 400mm
5 2 x Long Support Plate - 570mm
To Next Page
