1 Label n/a 1
2 Screw Rod 1510021 1
3 Spring Pin n/a 1
4 Screw n/a 1
5 Handle 14008302 1
6 Nut Hex n/a 1
7 Hand Wheel 14900601 1
8 Knob 15100801 1
9 Flat Washer n/a 1
10 Screw n/a 1
11 Nut Hex n/a 1
12 Flat Washer n/a 1
13 Pointer Bracket 15101301 1
14 Screw n/a 1
15 Pointer 15101501 1
16 NVR Switch 2898D05G04 1
17 Label n/a 1
18 Segment Gear n/a 1
19 Base 15102001 1
20 Bolt GB5780-88 4
21 Circuit Breaker 1853U55502 1
22 Switch Box 15102501 1
23 Power Cable 2807BB0601 1
24 Bolt GB5780-88 1
25 Spring Pin GB879-86 1
26 Bolt GB5780-88 3
27 Bracket 15103201 1
28 Spacer 14920301 1
29 Screw GB5780-88 6
30 Strap 14921402 3
31 Rod 14921302 1
32 Spring Washer GB93-87 6
33 Nut Hex GB6170-86 6
34 Flat Washer GB972-85 1
35 Spring 14922201 1
36 Spring 14922101 1
37 Flat Washer GB972-85 1
38 Nut Hex GB6170-86 1
39 Flat Washer GB972-85 1
40 Nut Hex GB6170-86 1
41 Spacer 14922901 1
42 Bolt n/a 1
43 Bracket 15104901 1
44 Bolt GB5780-88 4
45 Nut Hex GB6172-86 2
46 Set Screw Hex GB77-85 1
47 Spring 14901302 1
48 Detent Pin 14901202 1
49 Bracket 15105501 1
50 Bolt Hex GB5780-88 1
51 Nut Hex BG6170-86 1
52 Bracket 15106101 1
53 Bracket 15106201 1
54 Saddle 14921001 1
55 Hex Bolt M6 x 55mm n/a 1
56 Int Tooth Washer n/a 1
57 Guard Support n/a 1
58 Flat Washer n/a 2
59 Motor 8397029004 1
60 Saw Blade 29000011 1
61 Arbour Collar 14930101 1
62 Nut 14930001 1
63 Warning Label 14902902 1
64 Insert 15109661 1
65 Screw n/a 2
66 Table 15109801 1
67 Bottom Cover 1006 1
68 Screw n/a 6
69 Flat Washer n/a 6
70 Spring Washer n/a 6
71 Hex Nut n/a 6
72 Short Spacer 9003 2
73 Hex Nut n/a 2
74 Riving Knife Base 9001 1
75 Riving Knife n/a 1
76 Bolt Hex n/a 2
77 Cable Grommet 9004 1
78 Bolt n/a 4
79 Spring Washer n/a 4
80 Fender 2023 1
81 Nut n/a 1
82 Hex Nut n/a 1
83 Cable Grommet n/a 1
84 Bolt n/a 2
85 Nut n/a 2
86 Screw n/a 4
87 Hex Nut n/a 8
88 Nut n/a 4
89 Double Hex Rod n/a 2
90 Nut n/a 2
91 Bolt n/a 2
92 Nut n/a 2
93 Hex Nut n/a 3
95 Screw n/a 1
96 Ext Lockwasher n/a 1
97 Screw n/a 1
98 Capacitor RF n/a 1
Additional Items
1. Arbour Spanner Page 9, Item G 15106401 1
2. Blade Nut Spanner Page 9, Item H 14014801 1
3. Push Stick Page 9, Item F 11001 1
No. Description Part No Qty
26
No. Description Part No Qty
