Classen 60-RT - 72-Rt Tow Aerator; Parts Main Frame

25
QTY/PER
KEY PART NO. SHEET DESCRIPTION
1 400060 1 LIFT ROD
2 100099 1 3/4" x 4-1/2" HITCH PIN
3 100069 1 DECAL, "DANGER"
4 400159 1 MAIN FRAME
5 400062 1 R.H SIDE PLATE
6 400063 2 LATCH PIN
7 100100 2 SPRING
8 400064 2 WHEEL FORK
9 100103 2 TIRE & WHEEL ASSEMBLY
10 100074 3 DECAL, "CLASSEN"
11 500182 2 3/16" X 1-1/2" COTTER PIN
12 300052 1 WHEEL FORK AXLE
13 500129 8 3/8" NUT
14 500130 8 3/8" LOCK WASHER
15 100101 4 1" PILLOW BLOCK BEARING
16 500042 8 3/8" FLAT WASHER
17 500159 8 3/8" x 3" BOLT
18 100032 72 TINE
Parts Main Frame
72-RT TOW AERATOR
(S.N. 144 & UP)
PARTS LIST
QTY/PER
KEY PART NO. SHEET DESCRIPTION
19 700029 2 TINE SHAFT
20 300106 2 TINE END SPACER
21 300058 2 CENTER BEARING SPACER
22 500211 48 5/16" x 1-3/4" GR. 8 BOLT
23 500169 48 5/16" LOCK NUT
24 100055 1 DECAL, "SERIAL NUMBER" (not shown)
25 400065 1 L.H. SIDE PLATE
26 500016 4 5/32" x 1-1/4" COTTER PIN
27 500053 4 5/8" FLAT WASHER
28 300045 2 WHEEL AXLE
29 100104 2
7/8" LIFT ARM PIN w/ LOCK WASHER & NUTS
30 500311 1 1/2" LOCK NUT
31 400058 1 HITCH
32 500213 2 3/4" X 4" BOLT
33 500214 2 3/4" NUT
34 500195 2 3/4" LOCK WASHER
35 400059 1 HITCH GUSSET
36 500215 1 1/2" x 3" BOLT
72-RT TOW AERATOR
