System Map: Front, Left, Right & Rear Views (Models D & E)
Front
Figure 11
Front, Left, Right & Rear
Views (Models D & E)
1. LED Power Indicators
2. Mini-IEEE 1394a Port
3. RJ-45 LAN Jack
4. Powered USB 3.0 Port
(See Below)
5. USB 3.0 Port
6. Combined eSATA/ USB 3.0
Port
7. Multi-in-1 Card Reader
8. Optical Device Drive Bay
9. Emergency Eject Hole
10. Headphone Jack
11. Microphone Jack
12. S/PDIF-Out Jack
13. Line-In Jack
14. USB 2.0 Port
15. Security Lock Slot
16. Vent
17. DisplayPort
18. HDMI-Out Port
19. Mini DisplayPort
20. DC-In Jack
5
7
8
1
2
3
10
12
11
4
14
16
13
15
20
17
18
19
Left
Right
Rear (Model D)
6
9
16

USB
The USB 3.0 ports
are colored blue. USB 3.0 will transfer data much faster than USB 2.0, and
is backwards-compatible with USB 2.0. When the powered USB 3.0 port
is on it will sup-
ply power (for charging devices only, not for operating devices) when the system is off
but still powered by the AC/DC adapter plugged into a working outlet, or powered by the bat-
tery with a capacity level above 20% (this may not work with certain devices - see page 35).
Toggle power to this port by using Fn + power button.
4
16
15
20
17
18
19
Rear (Model E)
16
