Clevo P150SM

38
English
Interface
Three USB 3.0 Ports (Including one AC/DC
Powered USB port)
One USB 2.0 Port
One eSATA Port (USB 3.0 Port Combined)
One HDMI-Out Port
One DisplayPort (1.1a)
One
Mini DisplayPort
One S/PDIF Out Jack
One Headphone/Speaker-Out Jack
One Microphone-In Jack
One Line-In Jack
One Mini-IEEE1394a Port
One RJ-45 LAN Jack
One DC-In Jack
Note: External 7.1CH Audio Output Sup-
ported by Headphone, Microphone, Line-In
and S/PDIF Out Jacks
Communication
Built-In Giga Base-TX Ethernet LAN
2M FHD PC Camera Module
WLAN/ Bluetooth Half Mini-Card
Modules:
(Factory Option) Intel® Centrino® Ulti-
mate-N 6300 Wireless LAN (802.11a/g/n)
(Factory Option) Intel® Centrino®
Advanced-N 6235 Wireless LAN (802.11a/g/
n) + Bluetooth 4.0
(Factory Option) Intel® Centrino® Wire-
less-N 2230 Wireless LAN (802.11b/g/n) +
Bluetooth 4.0
(Factory Option) Wireless LAN (802.11b/g/
n) + Bluetooth 4.0
Environmental Spec
Temperature
Operating: 5
°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Removable 8-cell Smart Lithium-Ion Battery
Pack
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
Models A & B:
DC Output: 19.5V, 9.2A/ 19V, 9.47A (180W)
Model C :
DC Output: 19.5V, 6.15A (120W)
Models D & E :
DC Output: 19.5V, 11.8A (230W)
Dimensions & Weight
Models A & C:
376mm (w) * 256mm (d) * 35 - 43mm (h)
Around 3.1kg with Battery and ODD
Model B:
375mm (w) * 268mm (d) * 22 - 45mm (h)
Around 3.3kg with Battery and ODD
Model D:
412mm (w) * 276mm (d) * 41.5 - 41.8mm (h)
Around 3.9kg with Battery and ODD
Model E:
414mm (w) * 286mm (d) * 25.3 - 46.1mm (h)
Around 4.1kg with Battery and ODD
