Clevo P151SM-A - External Locator - Left Side & Rear View

Introduction
1 - 6 External Locator - Left Side & Rear View
1.Introduction
External Locator - Left Side & Rear View
Figure 4
Left Side View
1. Mini-IEEE 1394a
Port
2. RJ-45 LAN Jack
3. USB 3.0 Ports
4. Combined eSATA/
Powered USB 3.0
Port
5. Multi-in-1 Card
Reader
4
5
1
2
3
Left
3
Figure 5
Rear View
1. Vent/Fan Intake
2. Display Port
3. HDMI-Out Port
4. Mini Display Port
5. DC-In Jack
Rear
4
5
1
2
3
1
