Clevo P151SM-A - Disassembly - SSD Removal; Procedure for SSD Removal

Disassembly
2 - 10 Removing the SSD
2.Disassembly
Removing the SSD
Note that the SSD (if installed) is located under the HDD bay.
1. Turn off the computer, and turn it over, remove the battery (
page 2 - 5) and HDD (page 2 - 6).
2. Remove screws - from shielding plate (
Figure 6a).
3. Carefully remove the SSD shielding plate and remove the screw from the SSD (
Figure 6b).
4. The SSD module will pop-up and you can remove it from the computer (
Figure 9c
).
5. Reverse the process to install a new SSD.

3. SSD Shielding Plate
5. SSD Module
•3 Screws
Figure 6
SSD Removal
a. Remove the screws.
b. Remove the shielding
plate and screw.
c. Remove the SSD mod-
ule.
1
2
6
3
4
6
5
a. b.
4
3
1
2
5
c.
