Clevo PA71HS User Manual

Introduction
Specifications 1 - 3
1.Introduction
Pointing Device
(Factory Option) Built-In Secure Pad (with Microsoft PTP
Multi Gesture & Scrolling Functionality)
Or
(Factory Option) Built-in Touchpad ( (with Microsoft PTP
Multi Gesture & Scrolling Functionality)
Keyboard
(Factory Option) Full-size Illuminated White LED Winkey
Keyboard (with numeric keypad)
Or
(Factory Option) Full Color Illuminated Full-size Winkey
Keyboard (with numeric keypad)
Audio
High Definition Audio Compliant Interface
S/PDIF Digital Output
Two Speakers
Sound BlasterX® Pro-Gaming 720°
ANSP™ 3D sound technology on headphone output
Built-In Array Microphone
One Sub-Woofer
Note: External 5.1CH Audio Output Supported by 2-in1
Audio, Microphone-In and Headphone-Out Jacks
Card Reader
Embedded Multi-In-1 Push-Push Card Reader
MMC (MultiMedia Card)/RS MMC
SD (Secure Digital)/Mini SD/SDHC/ SDXC (up to UHS-II)
Communication
Built-In 10/100/1000Mb Base-TX Ethernet LAN
2.0M FHD PC Camera Module
WLAN/ Bluetooth M.2 Modules:
(Factory Option) Intel® Wireless-AC 8265 Wireless LAN
(802.11ac) + Bluetooth
(Factory Option) Intel® Wireless-AC 3168 Wireless LAN
(802.11ac) + Bluetooth
(Factory Option) Qualcomm® Atheros Killer™ Wireless-AC
1535 Wireless LAN (802.11ac) + Bluetooth
(Factory Option) Qualcomm® Wireless LAN (802.11ad) +
Bluetooth
M.2 Slots
Slot WLAN for Combo WLAN and Bluetooth Module
Slot SSD1 for SATA or PCIe Gen3 x4 SSD
Slot SSD2 for SATA or PCIe Gen3 x2 SSD

Intel® Optane™ SSD Module Installation
Service personnel please note that Intel® Op-
tane™ modules must be installed in the SSD1
slot.
Interface
One USB 3.0 (USB 3.1 Gen 1) Type-C Port*
*The maximum amount of current supplied by USB Type-C
ports is 500mA (USB 2.0)/900mA (USB 3.1).
Or
(Factory Option) One USB 3.1 Gen 2/Thunderbolt 3 Combo
Port (Type-C)
Four USB 3.0 (USB 3.1 Gen 1) Ports (Including one AC/DC
Powered USB port)
Two Mini DisplayPorts (1.3)
One HDMI-Out Port
One 2-In-1 Audio Jack (Line-Out & S/PDIF-Out (Optical)
Combo Jack)
One Microphone-In Jack
One Headphone-Out Jack
One RJ-45 LAN Jack
One DC-In Jack
Environmental Spec
Temperature
Operating: 5°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Embedded 4-Cell Polymer Battery Pack, 66WH
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19.5V, 11.8A (230W)
Dimensions & Weight
418.5mm (w) * 287mm (d) * 24.9mm (h)
3.0kg (Barebone with 66WH Battery)
