Mainboard Overview - Bottom (Connectors) 1 - 11
1.Introduction
Mainboard Overview - Bottom (Connectors)
Figure 10
Mainboard Bottom
Connectors
1. Card Reader Board
Connector
2. Audio Board
Connector
3. Battery Connector
4. VGA Fan
Connector
5. HDD Cable
Connector
6. FP Cable
Connector
7. Click Board
Connector
8. USB Board
Connector
9. LED Board
Connector
10.DC Board
Connector
11. CPU Fan
Connector
12.LCD Connector
13.CCD Connector
6
8
1
2
4
3
5
11
9
10
1
4
7
10
12
13
