Disassembly
Removing the Battery 2 - 7
2.Disassembly
6. The battery will be visible at point on the computer (Figure 3d).
7. Carefully disconnect the cable , then remove screws
- (Figure 3e).
8. Lift the battery off the computer (Figure 3f
).
9. Reverse the process to install a new battery (do not forget to replace all the screws and bottom cover).
Figure 3
Battery Removal
(cont’d.)
d. Locate the battery.
e. Disconnect the cable and
remove the screws.
f. Lift the battery off the
computer.
To Next Page
