Mainboard Overview - Top (Connectors)
Figure 9
Mainboard Top
Connectors
1. Per Key Cable
Connector
2. Keyboard Cable
Connector
3. LED Keyboard
Cable Connector
4. Power Switch
Connector
5. Multi-in-1 Card
Reader
6. USB 3.1 Gen 2
Type-C Port
Or
(Factory Option)
Thunderbolt 3
Port
7. USB 3.0 (USB 3.1
Gen 1) Type-A
Port
10
11
7
6
5
1
3
4
2
