About Advanced Features & Operation
36
1 Place the thermostat in the OFF mode.
2 Press and hold the MODE button. While
holding the MODE button, press and hold
the DOWN button for 5 seconds.
All icons will appear on the display.
3 Press the MODE button once. The thermostat
temperature will be displayed and may be
calibrated using the UP or DOWN buttons. The
calibrated oset from the “raw” temperature
reading is displayed in the lower right corner.
Additionally, on this screen you may view the
Software Version in the upper left corner.
4 After calibration is complete, press the
MODE button once to save your changes
and return to normal operation.
MODE
MODE
MODE
MODE
Calibration
Under normal circumstances it will not be necessary to adjust the
calibration of the temperature sensor. If calibration is required, please
contact a trained HVAC technician to correctly perform the following
procedure.
