Advanced Setup Table
39
FD = Factory Default Setting
Step# Description Pg# Range FD
1 CLOCK 18 12A - 12A 12P
2 WEEKDAY 18 Monday - Sunday Monday
3 SHOW CLOCK 18 On, Off On
4 PROG 19 On, Off On
5 BACKLIGHT 19 On, Off Off
6 NIGHTLT 19 On, Off Off
7 NIGHTLT START 19 12A - 12A 8:00P
8 NIGHTLT STOP 19 12A - 12A 6:00A
9 MAX OVRRIDE TIME IN HOURS 20 0 - 4 hrs 4
10 FAN 20 on,auto auto
11 DISPLAY F/C 20 F, C F
12 MINIMUM HEAT/COOL SPREAD 20 0 - 6 degrees 2
13 SETPOINT LIMITS 21 on,off off
14 MAX HEAT SETPOINT 21 35 - 99 degrees 82
15 MIN COOL SETPOINT 21 35 - 99 degrees 66
16 AVAILABLE MODES 21 auto, cool, heat, cool & heat auto
17 1ST STAGE DEADBAND 22 1 - 6 degrees 2
18 2ND STAGE DEADBAND 22 0 - 10 degrees 2
19 MINUTES BETWEEN 1st AND 2nd STAGE 22 0 - 60 min 2
20 2ND STAGE TURNOFF POINT 22 deadband, setpoint deadband
21 FAN OFF DELAY 23 0, 30, 60, 90 seconds 0
22 FILTER RUNTIME 24 runtime in hours
23 FILTER RUNTIME 24 runtime in days
24 SERVICE FILTER ALERT HOURS 24 off - 2000 hrs off
25 SERVICE FILTER ALERT DAYS 24 off - 720 days off
26 PRE-OCC FAN PURGE TIME 25 off - 3 hrs off
27 COMFORT RECOVRY 25 On, Off Off
28 DRY CONTACT POLARTY 26 NORMAL OPENED, NORMAL
NORMAL CLOSED OPENED
29 DRY CONTACT USE 26 occupied, condensate, fdd, FDD
holiday
(continued)
