ClimateMaster iGate Connect - Specifications; Wiring Requirements

8
Speci cations
Temperature ranges
Heat: 55 to 80 °F (12 to 27 °C)
Cool: 65 to 95 °F (18 to 35 °C)
Display: 40 to 100 °F (5 to 37 °C)
Sensitivity: +/– 1 °F (0.5 °C)
Operating: 32 to 130 °F (0 to 55 °C)
Humidity Range
Display: 20 to 90% R.H.
Sensitivity: +/– 5% R.H.
Operating: 5 to 95% R.H (non–condensing)
Dimensions
Thermostat: 5.5”W x 3.25”H x 1”D
(139.5mm H x 82.5mm W x 25mm D)
Power
24 VAC (3VA maximum)
Wiring Requirements
The following table shows the maximum wire lengths allowed:
Thermostat to HVAC Equipment
18 AWG 20 AWG 22 AWG
1250 ft/380 800 ft/240 m 500 ft/150 m
