27
AWS Tank – WXM Controller (If Applicable)
Model Displays the unit model number
Serial Number Displays the storage tank serial
number
Diagnostics
– Upper Tank Temp – displays the temperature
of the DHW at the upper element of the
storage tank.
– Lower Tank Temp – displays the temperature
of the DHW at the lower element of the
storage tank.
– Hot Water T3 Temp – not used.
– Hot Water T4 Temp – not used.
Sensors
Con gures sensors to be displayed at thermostat.
Sensors
– RS–1(sensor name) This is sensor number
1. It will not display a name until a name has
been entered.
o Name Establishes a name for sensor 1.
o Type Con gures the type of sensor.
The sensor may be a dry contact or a
temperature sensor. If a temperature
sensor, the installer selects the
manufacturer, model, and a temperature
correction for the sensor.
o Usage Con gures the type of use for
the sensor. Available options are Control
To con gure the sensors
on the iGate
™
Connect
thermostat:
From the Home screen,
press MENU.
Select Settings ▶
Installation.
Select Sensors.
To Next Page
