THE SMART SOLUTION FOR ENERGY EFFICIENCY
Tranquility
®
Compact Belt Drive (TCH/V) Series
Rev.: July 25, 2017
9
climatemaster.com
Unit with WSE Option
TCV Physical Data
Model
072 096 120 160 192 240 300
Compressor Scroll
Number of Circuits (Compressors) 2
Factory Charge HFC-410a - (oz)
[kg] per circuit
60 [1.70] 76 [2.15] 80 [2.27] 112 [3.18] 136 [3.86] 196 [5.56] 224 [6.35]
Blower Motor
Blower Motor Quantity 1
Standard Motor (hp) [kw] 1 [.75] 2 [1.49] 3 [2.23] 3 [2.24] 3 [2.24] 5 [3.73] 7.5 [5.60]
Optional Large Motor (hp) [kw] 2 [1.49] 3 [2.24] 5 [3.73] 5 [3.73] 5 [3.73] 7.5 [5.59] 10 [7.46]
Blower
No. of Blowers 1 2 3
Blower Wheel Size D x W (in) [cm] 12 x 12 [30.48 x 30.48]
Water Connection Size
FPT (in) [mm] 1-1/4" [31.8] 1-1/2" [38.1] 2" [50.8] 2-1/2" [63.5]
Coax Volume
Volume (US Gallons) [liters] 1.62 [6.13] 1.81 [6.85] 2.40 [9.08] 3.62 [13.70] 4.83 [18.28] 4.90 [18.55] 7.39 [27.98]
Condensate Connection Size
FPT (in) [mm] 1" [25.4]
Air Coil Data
Air Coil Dimensions H x W (in) [cm] 32 x 34 [81.28 x 86.36] 36 x 36 [91.44 x 91.44] 36 x 76 [91.44 x 193.04]
Air Coil Total Face Area (ft
2
) [m
2
] 7.6 [0.71] 9.0 [0.84] 19 [1.77]
Air Coil Tube Size (in) [cm] 3/8" [0.953]
Air Coil Fin Spacing (fpi)
[ ns per cm]
14 [5.5] 12 [4.72]
Air Coil Number of Rows 3 2 3 4
Miscellaneous Data
Filter Standard - 1" [25.4mm]
Throwaway (qty) (in) [cm]
(QTY.4) 20 x 20 [50.8 x 50.8]
(QTY.4) 20 x 25 [50.80 x 63.5]
(QTY.2) 20 x 30 [50.80 x 76.2]
Weight - Operating (lbs) [kg] 586 [265.8] 644 [292.1] 698 [316.6] 1069 [484.9] 1164 [528.0] 1184 [537.1] 1297 [588.3]
Weight - Packaged (lbs) [kg] 626 [283.9] 684 [310.3] 738 [334.8] 1149 [521.2] 1244 [564.3] 1264 [573.3] 1377 [624.6]
TCV Series 072 096 120 160 192 240 300
Water Coil Dimensions (in x cm)
32 x 34 [81.28 x
86.36]
35 x 36 [88.9 x 91.4] 35 x 76 [88.9 x 193]
Internal Water Coil Volume (Gal) [L]
5.9 [22.3] 6.6 [25] 7.2 [27.3] 13.3 [50.3] 14.5 [54.9] 23.9 [90.5] 26.4 [99.9]
Weight - Operating (lbs.) [Kg]
762 [346] 837 [378] 907 [411] 1529 [694] 1665 [755] 1693 [768] 1855 [841]
Weight - Packaged (lbs.) [Kg]
814 [369] 889 [403] 962 [436] 1643 [745] 1779 [807] 1808 [820] 1974 [895]
