Electrical Data – ECM Blower
TR Commercial Electrical Table ECM-CV** ECM-CT
MODEL
VOLTAGE
CODE
RATED
VOLTAGE
VOLTAGE
MIN/MAX
COMPRESSOR
FAN
MOTOR
FLA
TOTAL
UNIT
FLA
MIN
CIRCUIT
AMP
MAX
FUSE/
HACR
FAN
MOTOR
FLA
TOTAL
UNIT
FLA
MIN
CIRCUIT
AMP
MAX
FUSE/
HACR
QTY RLA LRA
006
G
208-230 /
60 / 1
187.2 / 253 1 2.6 17.7 1.5 4.1 4.8 15A 2.3 4.9 5.6 15A
E 265 / 60 / 1 238.5 / 291.5 1 2.6 13.5 1.4 4.0 4.7 15A 2.3 4.9 5.6 15A
009
G
208-230 /
60 / 1
187.2 / 253 1 3.7 22 1.5 5.2 6.1 15A 2.3 6.0 6.9 15A
E 265 / 60 / 1 238.5 / 291.5 1 3.4 17.5 1.4 4.8 5.7 15A 2.3 5.7 6.6 15A
012
G
208-230 /
60 / 1
187.2 / 253 1 5.6 32.5 2.6 8.2 9.6 15A 2.3 7.9 9.3 15A
E 265 / 60 / 1 238.5 / 291.5 1 4.2 31.5 2.5 6.7 7.8 15A 2.3 6.5 7.6 15A
015
G
208-230 /
60 / 1
187.2 / 253 1 5.6 29 2.6 8.2 9.6 15A 2.6 8.2 9.6 15A
E 265 / 60 / 1 238.5 / 291.5 1 5.0 28 2.4 7.4 8.7 15A 1.9 6.9 8.2 15A
018
G
208-230 /
60 / 1
187.2 / 253 1 7.4 33 2.6 10.0 11.9 15A 2.6 10.0 11.9 15A
E 265 / 60 / 1 238.5 / 291.5 1 6.0 28 2.4 8.4 9.9 15A 1.9 7.9 9.4 15A
024
G
208-230 /
60 / 1
187.2 / 253 1 12.8 58.3 3.9 16.7 19.9 30A 3.9 16.7 19.9 30A
E 265 / 60 / 1 238.5 / 291.5 1 9.6 54 3.2 12.8 15.2 20A 3.2 12.8 15.2 20A
F** 460 / 60 / 3 414 / 506 1 3.6 28 3.2 6.8 7.7 15A 1.1 4.7 5.6 15A
H
208-230 /
60 / 3
187.2 / 253 1 7.7 55.4 3.9 11.6 13.5 20A 3.9 11.6 13.5 20A
030
G
208-230 /
60 / 1
187.2 / 253 1 14.1 73 3.9 18.0 21.5 35A 3.9 18.0 21.5 35A
E 265 / 60 / 1 238.5 / 291.5 1 11.2 60 3.2 14.4 17.2 25A 3.2 14.4 17.2 25A
F** 460 / 60 / 3 414 / 506 1 4.2 28 3.2 7.4 8.5 15A 1.1 5.3 6.4 15A
H
208-230 /
60 / 3
187.2 / 253 1 8.9 58 3.9 12.8 15.0 20A 3.9 12.8 15.0 20A
036
G
208-230 /
60 / 1
187.2 / 253 1 16.7 79 6.0 22.7 26.9 40A 6.0 22.7 26.9 40A
E 265 / 60 / 1 238.5 / 291.5 1 13.5 72 4.8 18.3 21.7 35A 3.9 17.4 20.8 30A
F** 460 / 60 / 3 414 / 506 1 5.8 38 4.8 10.6 12.1 15A 1.5 7.3 8.8 15A
H
208-230 /
60 / 3
187.2 / 253 1 10.4 73 6.0 16.4 19.0 25A 6.0 16.4 19.0 25A
042
G
208-230 /
60 / 1
187.2 / 253 1 17.9 112 6.0 23.9 28.4 45A 6.0 23.9 28.4 45A
F** 460 / 60 / 3 414 / 506 1 6.0 44 4.8 10.8
12.3 15A 1.5 7.5 9.0 15A
H
208-230 /
60 / 3
187.2 / 253 1 13.5 88 6.0 19.5 22.9 35A 6.0 19.5 22.9 35A
048
G
208-230 /
60 / 1
187.2 / 253 1 21.8 117 7.5 29.3 34.8 50A 7.5 29.3 34.8 50A
F** 460 / 60 / 3 414 / 506 1 6.2 41 6.2 12.4 14.0 15A 2.1 8.3 9.9 15A
H
208-230 /
60 / 3
187.2 / 253 1 13.7 83.1 7.5 21.2 24.6 35A 7.5 21.2 24.6 35A
060
G
208-230 /
60 / 1
187.2 / 253 1 26.3 134 7.5 33.8 40.4 60A 7.5 33.8 40.4 60A
F** 460 / 60 / 3 414 / 506 1 7.8 52 6.0 13.8 15.8 20A 2.1 9.9 11.9 15A
H
208-230 /
60 / 3
187.2 / 253 1 15.6 110 7.5 23.1 27.0 40A 7.5 23.1 27.0 40A
** 460 volt units with Internal Secondary Pump and/or ECM-CV Require a Neutral
