CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
(TR) Series
Rev.: November 2, 2020
ClimateMaster Water-Source Heat Pumps
Electrical Data – ECM Blower with Internal Secondary Pump
TR Commercial Electrical Table W/ ISP ECM-CV** ECM-CT
MODEL
VOLTAGE
CODE
RATED
VOLTAGE
VOLTAGE
MIN/MAX
COMPRESSOR
PUMP
FLA
FAN
MOTOR
FLA
TOTAL
UNIT
FLA
MIN
CIRCUIT
AMP
MAX
FUSE/
HACR
FAN
MOTOR
FLA
TOTAL
UNIT
FLA
MIN
CIRCUIT
AMP
MAX
FUSE/
HACR
QTY RLA LRA
006
G
208-230 /
60 / 1
187.2 / 253 1 2.6 17.7 0.4 1.5 4.5 5.2 15A 2.3 5.3 6.0 15A
E 265 / 60 / 1 238.5 / 291.5 1 2.6 13.5 0.7 1.4 4.7 5.4 15A 2.3 5.6 6.3 15A
009
G
208-230 /
60 / 1
187.2 / 253 1 3.7 22 0.4 1.5 5.6 6.5 15A 2.3 6.4 7.3 15A
E 265 / 60 / 1 238.5 / 291.5 1 3.4 17.5 0.7 1.4 5.5 6.4 15A 2.3 6.4 7.3 15A
012
G
208-230 /
60 / 1
187.2 / 253 1 5.6 32.5 0.8 2.6 9.0 10.4 15A 2.3 8.7 10.1 15A
E 265 / 60 / 1 238.5 / 291.5 1 4.2 31.5 0.7 2.5 7.4 8.5 15A 2.3 7.2 8.3 15A
015
G
208-230 /
60 / 1
187.2 / 253 1 5.6 29 0.8 2.6 9.0 10.4 15A 2.6 9.0 10.4 15A
E 265 / 60 / 1 238.5 / 291.5 1 5.0 28 0.7 2.4 8.1 9.4 15A 1.9 7.6 8.9 15A
018
G
208-230 /
60 / 1
187.2 / 253 1 7.4 33 0.8 2.6 10.8 12.7 20A 2.6 10.8 12.7 20A
E 265 / 60 / 1 238.5 / 291.5 1 6.0 28 0.7 2.1 8.8 10.3 15A 1.9 8.6 10.1 15A
024
G
208-230 /
60 / 1
187.2 / 253 1 12.8 58.3 0.8 3.9 17.5 20.7 30A 3.9 17.5 20.7 30A
E 265 / 60 / 1 238.5 / 291.5 1 9.6 54 0.7 3.2 13.5 15.9 25A 3.2 13.5 15.9 25A
F** 460 / 60 / 3 414 / 506 1 3.6 28 0.7 3.2 7.5 8.4 15A 1.1 5.4 6.3 15A
H
208-230 /
60 / 3
187.2 / 253 1 7.7 55.4 0.8 3.9 12.4 14.3 20A 3.9 12.4 14.3 20A
030
G
208-230 /
60 / 1
187.2 / 253 1 14.1 73 0.8 3.9 18.8 22.3 35A 3.9 18.8 22.3 35A
E 265 / 60 / 1 238.5 / 291.5 1 11.2 60 0.7 3.2 15.1 17.9 25A 3.2 15.1 17.9 25A
F** 460 / 60 / 3 414 / 506 1 4.2 28 0.7 3.2 8.1 9.2 15A 1.1 6.0 7.1 15A
H
208-230 /
60 / 3
187.2 / 253 1 8.9 58 0.8 3.9 13.6 15.8 20A 3.9 13.6 15.8 25A
036
G
208-230 /
60 / 1
187.2 / 253 1 16.7 79 0.8 6.0 23.5 27.7 40A 6.0 23.5 27.7 40A
E 265 / 60 / 1 238.5 / 291.5 1 13.5 72 0.7 4.8 19.0 22.4 35A 3.9 18.1 21.5 30A
F** 460 / 60 / 3 414 / 506 1 5.8 38 0.7 4.8 11.3 12.8 15A 1.5 8.0 9.5 15A
H
208-230 /
60 / 3
187.2 / 253 1 10.4 73 0.8 6.0 17.2 19.8 25A 6.0 17.2 19.8
30A
042
G
208-230 /
60 / 1
187.2 / 253 1 17.9 112 0.8 6.0 24.7 29.2 45A 6.0 24.7 29.2 45A
F** 460 / 60 / 3 414 / 506 1 6.0 44 0.7 4.8 11.5 13.0 15A 1.5 8.2 9.7 15A
H
208-230 /
60 / 3
187.2 / 253 1 13.5 88 0.8 6.0 20.3 23.7 35A 6.0 20.3 23.7 35A
048
G
208-230 /
60 / 1
187.2 / 253 1 21.8 117 1.1 7.5 30.4 35.9 50A 7.5 30.4 35.9 50A
F** 460 / 60 / 3 414 / 506 1 6.2 41 1.3 6.2 13.7 15.3 20A 2.1 9.6 11.2 15A
H
208-230 /
60 / 3
187.2 / 253 1 13.7 83.1 1.1 7.5 22.3 25.7 35A 7.5 22.3 25.7 35A
060
G
208-230 /
60 / 1
187.2 / 253 1 26.3 134 1.1 7.5 34.9 41.5 60A 7.5 34.9 41.5 60A
F** 460 / 60 / 3 414 / 506 1 7.8 52 1.3 6.0 15.1 17.1 20A 2.1 11.2 13.2 20A
H
208-230 /
60 / 3
187.2 / 253 1 15.6 110 1.1 7.5 24.2 28.1 40A 7.5 24.2 28.1 40A
** 460 volt units with Internal Secondary Pump and/or ECM-CV Require a Neutral
