ClimateMaster Water-Source Heat Pumps
Blower Performance Data – TR Hybrid 009
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
325 225
ECM -
Constant
Torque
1
RPM 1199 1256 1310 1373 1452
Power (W) 50 53 55 57 60
CFM 283 269 255 243 229
2
RPM 1325 1374 1431 1477 1541 1605 1670 1730 1783
Power (W) 60 63 65 67 70 71 74 76 78
CFM 332 314 298 286 276 263 251 239 228
3
RPM 1461 1505 1553 1600 1645 1699 1746 1804 1823 1843
Power (W) 80 83 85 88 90 93 95 98 100 103
CFM 374 358 348 338 328 321 302 287 256 223
4
RPM 1819 1834 1822 1827 1849
Power (W) 130 120 110 100 90
CFM 372 353 300 265 231
325 225
ECM -
Constant
Volume
Minimum CFM
RPM 976 1080 1182 1290 1401 1499 1601 1709 1814 1918
Power (W) 33 41 50 56 60 71 80 86 93 101
CFM 225 225 225 225 225 225 225 225 225 225
Default CFM
RPM 1684 1714 1753 1754 1765 1795
Power (W) 110 109 110 104 100 99
CFM 325 325 325 325 325 325
Maximum CFM
RPM 1757 1766 1774 1783
Power (W) 120 108 100 98
CFM 375 375 375 375
Interpolation is permissible; extrapolation is not.
All performance is based upon the lower voltage of dual voltage rated units.
Performance stated is at the rated power supply; performance may vary as the power supply varies from the rated.
See performance correction tables for operating conditions other than those listed above.
