Blower Performance Data – TR Hybrid 012
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
400 300
ECM -
Constant
Torque
1
RPM 1402 1449 1492 1539 1597
Power (W) 70 73 75 78 80
CFM 348 335 325 311 299
2
RPM 1524 1570 1604 1649 1690 1737 1794
Power (W) 90 93 97 100 103 107 110
CFM 377 374 365 354 345 335 317
3
RPM 1727 1765 1790 1794 1796 1802 1807
Power (W) 130 128 124 121 120 115 110
CFM 435 427 416 397 376 351 320
4
RPM 1760 1780 1784 1786 1796 1798 1816
Power (W) 140 137 132 130 122 117 110
CFM 445 432 416 391 376 354 324
400 300
ECM -
Constant
Volume
Minimum CFM
RPM 1318 1404 1487 1576 1667 1748 1831 1920 2006 2092
Power (W) 50 60 70 80 90 100 110 120 130 140
CFM 300 300 300 300 300 300 300 300 300 300
Default CFM
RPM 1648 1716 1787 1852 1913 1988 2059 2124 2192 2260
Power (W) 97 109 120 134 150 159 170 184 197 209
CFM 400 400 400 400 400 400 400 400 400 400
Maximum CFM
RPM 2023 2028 2032 2038 2045 2048 2052 2058 2063 2068
Power (W) 200 195 190 185 180 175 170 165 160 155
CFM 450 450 450 450 450 450 450 450 450 450
Interpolation is permissible; extrapolation is not.
All performance is based upon the lower voltage of dual voltage rated units.
Performance stated is at the rated power supply; performance may vary as the power supply varies from the rated.
See performance correction tables for operating conditions other than those listed above.
