Blower Performance Data – TR Hybrid 060
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
1950 1500
ECM -
Constant
Torque
1
RPM 856 886 916 946 978
Power (W) 448 462 476 490 505
CFM 1739 1693 1646 1595 1546
2
RPM 943 969 997 1026 1054 1081 1110 1140 1170 1199
Power (W) 622 637 654 670 687 702 719 736 753 770
CFM 1954 1915 1872 1828 1780 1736 1692 1648 1604 1562
3
RPM 1029 1053 1079 1106 1133 1159 1185 1210 1230 1250
Power (W) 833 850 868 887 906 925 943 960 957 953
CFM 2166 2126 2087 2045 2000 1954 1914 1872 1814 1755
4
RPM 1049 1073 1099 1125 1149 1169 1189 1208 1228 1248
Power (W) 897 915 934 952 963 959 955 952 948 946
CFM 2224 2186 2145 2107 2055 1988 1926 1864 1804 1745
5
RPM
Power (W)
CFM
1950 1500
ECM -
Constant
Volume
Minimum CFM
RPM 814 862 908 956 1006 1051 1097 1145 1192 1240
Power (W) 324 376 428 479 530 582 634 685 736 788
CFM 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500
Default CFM
RPM 1046 1072 1093 1123 1158 1175 1196
Power (W) 854 872 874 908 956 943 945
CFM 1950 1950 1950 1950 1950 1950 1950
Maximum CFM
RPM 1078 1097 1116
Power (W) 955 950 946
CFM 2200 2200 2200
Interpolation is permissible; extrapolation is not.
All performance is based upon the lower voltage of dual voltage rated units.
Performance stated is at the rated power supply; performance may vary as the power supply varies from the rated.
See performance correction tables for operating conditions other than those listed above.
