CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
(TR) Series
Rev.: November 2, 2020
ClimateMaster Water-Source Heat Pumps
Blower Performance Data – TR Hybrid 048
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
1500 1200
ECM -
Constant
Torque
1
RPM 731 770 807 840
Power (W) 251 263 275 285
CFM 1396 1328 1262 1206
2
RPM 798 833 867 900 931 963 1000
Power (W) 340 354 366 378 389 401 415
CFM 1576 1517 1449 1393 1343 1291 1235
3
RPM 864 902 935 965 995 1024 1054 1085 1121 1183
Power (W) 458 476 491 505 519 533 547 561 578 608
CFM 1767 1715 1655 1599 1546 1497 1449 1400 1345 1259
4
RPM 927 956 986 1016 1044 1084 1112 1138 1166 1194
Power (W) 598 615 632 649 666 682 698 713 729 747
CFM 1980 1928 1877 1824 1772 1697 1651 1609 1565 1521
5
RPM 1103 1129 1155 1181 1207 1232
Power (W) 831 848 866 885 904 921
CFM 1963 1916 1872 1830 1791 1755
1500 1200
ECM -
Constant
Volume
Minimum CFM
RPM 724 774 824 875 928 977 1026 1078 1129 1179
Power (W) 192 231 272 310 348 389 429 468 508 547
CFM 1200 1200 1200 1200 1200 1200 1200 1200 1200 1200
Default CFM
RPM 883 925 965 1008 1052 1091 1131 1174 1216 1257
Power (W) 408 453 498 544 589 634 679 725 770 815
CFM 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500
Maximum CFM
RPM 993 1031 1068 1109 1151 1187 1224 1264 1303 1342
Power (W) 625 678 730 786 843 893 945 1000 1054 1108
CFM 1900 1900 1900 1900 1900 1900 1900 1900 1900 1900
Interpolation is permissible; extrapolation is not.
All performance is based upon the lower voltage of dual voltage rated units.
Performance stated is at the rated power supply; performance may vary as the power supply varies from the rated.
See performance correction tables for operating conditions other than those listed above.
