Blower Performance Data – TR Hybrid 042
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
1400 1050
ECM -
Constant
Torque
1
RPM 883 918 954 992 1030
Power (W) 248 257 266 277 287
CFM 1189 1156 1126 1089 1053
2
RPM 970 1001 1033 1065 1097 1130 1168 1207 1245
Power (W) 338 349 359 370 380 391 403 417 429
CFM 1348 1320 1290 1259 1227 1195 1163 1124 1087
3
RPM 1068 1098 1126 1153 1182 1211 1240 1271 1302 1340
Power (W) 465 479 490 502 513 525 537 550 562 578
CFM 1513 1485 1460 1432 1405 1375 1349 1319 1287 1254
4
RPM 1160 1185 1213 1237 1262 1289 1314 1340 1367 1395
Power (W) 611 625 638 649 661 675 688 700 714 728
CFM 1679 1655 1628 1604 1577 1553 1529 1503 1476 1450
5
RPM 1271 1292 1309 1327 1346 1364 1385 1405
Power (W) 753 761 759 757 756 754 753 751
CFM 1736 1709 1672 1634 1595 1558 1514 1472
1400 1050
ECM -
Constant
Volume
Minimum CFM
RPM 816 870 921 976 1034
Power (W) 176 204 232 260 288
CFM 1050 1050 1050 1050 1050
Default CFM
RPM 986 1032 1077 1125 1173 1217 1262 1309 1356 1402
Power (W) 360 397 434 471 508 545 582 619 656 693
CFM 1400 1400 1400 1400 1400 1400 1400 1400 1400 1400
Maximum CFM
RPM 1265 1284
Power (W) 778 776
CFM 1750 1750
Interpolation is permissible; extrapolation is not.
All performance is based upon the lower voltage of dual voltage rated units.
Performance stated is at the rated power supply; performance may vary as the power supply varies from the rated.
See performance correction tables for operating conditions other than those listed above.
