ClimateMaster Tranquility TR Series - Page 52

52
CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
(TR) Series
Rev.: November 2, 2020
ClimateMaster Water-Source Heat Pumps
Blower Performance Data – TR Hybrid 036
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
1150 900
ECM -
Constant
Torque
1
RPM 791 831 872 912 954
Power (W) 180 189 198 206 215
CFM 1032 1003 970 938 903
2
RPM 838 875 912 950 990 1033 1071
Power (W) 218 227 236 246 255 265 275
CFM 1116 1089 1062 1031 997 963 930
3
RPM 902 937 971 1006 1041 1076 1111 1150 1193 1249
Power (W) 280 290 300 310 320 330 340 351 364 380
CFM 1229 1206 1180 1153 1125 1095 1068 1036 1001 944
4
RPM 993 1026 1057 1088 1119 1152 1184 1214 1247 1283
Power (W) 391 402 414 425 436 448 459 470 482 496
CFM 1398 1374 1354 1329 1304 1278 1252 1226 1201 1172
5
RPM 1046 1079 1107 1139 1170 1186 1226 1258 1287 1318
Power (W) 474 487 498 511 530 527 544 557 570 584
CFM 1503 1480 1458 1438 1428 1388 1361 1338 1313 1290
1150 900
ECM -
Constant
Volume
Minimum CFM
RPM 728 784 838 895 953 1006 1060 1117
Power (W) 126 148 171 193 215 238 261 284
CFM 900 900 900 900 900 900 900 900
Default CFM
RPM 883 931 976 1026 1077 1120 1166 1215 1263 1310
Power (W) 253 283 311 341 372 400 429 459 489 518
CFM 1150 1150 1150 1150 1150 1150 1150 1150 1150 1150
Maximum CFM
RPM 1023 1065 1107 1150 1194
Power (W) 446 485 524 563 601
CFM 1500 1500 1500 1500 1500
Interpolation is permissible; extrapolation is not.
All performance is based upon the lower voltage of dual voltage rated units.
Performance stated is at the rated power supply; performance may vary as the power supply varies from the rated.
See performance correction tables for operating conditions other than those listed above.
