Blower Performance Data – TR Hybrid 030
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
1000 750
ECM -
Constant
Torque
1
RPM 886 927 965 994 1040 1071 1101
Power (W) 205 214 222 229 239 246 252
CFM 916 886 857 837 799 772 749
2
RPM 969 1009 1045 1077 1109 1139 1168 1214 1234 1267
Power (W) 277 287 297 306 314 322 330 342 348 357
CFM 1030 1004 977 951 929 907 883 838 828 807
3
RPM 1058 1097 1131 1162 1192 1221 1249 1281 1322 1330
Power (W) 369 382 393 404 414 423 432 443 456 460
CFM 1147 1123 1098 1075 1052 1030 1012 986 947 949
4
RPM 1180 1213 1243 1272 1300 1326 1352 1377 1400
Power (W) 494 507 518 530 541 551 561 571 580
CFM 1244 1219 1198 1176 1152 1134 1116 1098 1082
5
RPM 1434 1458 1477
Power (W) 711 722 723
CFM 1246 1228 1200
1000 750
ECM -
Constant
Volume
Minimum CFM
RPM 841 892 942 994 1048 1096 1146 1198 1249 1300
Power (W) 160 184 208 232 256 280 304 328 352 375
CFM 750 750 750 750 750 750 750 750 750 750
Default CFM
RPM 1027 1070 1112 1156 1202 1243 1285 1330 1373 1416
Power (W) 324 354 383 413 443 472 502 532 561 591
CFM 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
Maximum CFM
RPM 1211 1245 1271 1312 1361 1379 1405
Power (W) 604 626 635 671 720 716 725
CFM 1250 1250 1250 1250 1250 1250 1250
Interpolation is permissible; extrapolation is not.
All performance is based upon the lower voltage of dual voltage rated units.
Performance stated is at the rated power supply; performance may vary as the power supply varies from the rated.
See performance correction tables for operating conditions other than those listed above.
