Blower Performance Data – TR Hybrid 024
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
800 600
ECM -
Constant
Torque
1
RPM 816 871 928 988 1045 1119
Power (W) 125 133 141 149 157 168
CFM 787 756 723 686 649 604
2
RPM 875 925 974 1030 1084 1137 1196 1271 1315
Power (W) 160 168 177 186 195 204 214 227 235
CFM 876 848 819 787 753 720 684 634 603
3
RPM 934 979 1026 1070 1124 1174 1224 1275 1339 1399
Power (W) 200 209 218 226 237 247 257 267 280 293
CFM 962 936 909 883 851 820 789 755 715 676
4
RPM 1083 1127 1167 1218 1263 1309 1355 1405
Power (W) 270 280 289 301 311 322 333 345
CFM 1004 980 954 925 896 867 838 807
5
RPM 1314 1357 1399 1444
Power (W) 380 391 403 416
CFM 1004 977 950 923
800 600
ECM -
Constant
Volume
Minimum CFM
RPM 766 833 899 967 1037 1101 1167 1235 1302 1369
Power (W) 80 99 118 136 154 174 193 211 229 248
CFM 600 600 600 600 600 600 600 600 600 600
Default CFM
RPM 890 950 1006 1071 1141 1192 1247 1312 1372 1433
Power (W) 148 172 194 218 244 265 287 312 335 359
CFM 800 800 800 800 800 800 800 800 800 800
Maximum CFM
RPM 1034 1088 1144 1195 1244 1302 1358 1409 1463 1516
Power (W) 256 285 316 343 368 401 432 459 488 517
CFM 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
Interpolation is permissible; extrapolation is not.
All performance is based upon the lower voltage of dual voltage rated units.
Performance stated is at the rated power supply; performance may vary as the power supply varies from the rated.
See performance correction tables for operating conditions other than those listed above.
