11 GENERAL TECHNICAL DATA
Sound levels - Extraquiet = Fan maximum speed
Size
Sound Power Level [dB]
Sound
Pressure Level
Sound
Power Level
Octave band (Hz)
63 125 250 500 1000 2000 4000 8000 dB(A) dB(A)
2.1
30 47 47 49 45 42 37 32
37 50
3.1
30 47 48 49 46 42 36 31
38 51
5.1
34 53 54 51 49 44 32 34
40 54
7.1
35 53 54 52 50 44 31 33
41 54
10.1 48
54 55
58 52 47 42 35 44 58
12.1
59
57 62
61 59 56 50 55
50 64
Sound levels - Quiet (standard) = Fan medium speed
Sound levels - Powerfull = Fan maximum speed
Size
Sound Power Level [dB]
Sound
Pressure Level
Sound
Power Level
Octave band (Hz)
63 125 250 500 1000 2000 4000 8000 dB(A) dB(A)
2.1
34 49 50 53 49 47 43 33
42 55
3.1
34 49 50 54 49 47 42 33
42 55
5.1
35 55 56 56 54 49 37 39
44 58
7.1
35 56 57 55 54 49 38 39
45 58
10.1
49 53 56 59 53 48 43 38
45 59
12.1
59 57 62 61 59 56 50 55
50 64
Size
Sound Power Level [dB]
Sound
Pressure Level
Sound
Power Level
Octave band (Hz)
63 125 250 500 1000 2000 4000 8000 dB(A) dB(A)
2.1
42 53 54 58 57 54 51 37
48 62
3.1
42 53 54 58 57 55 52 37
49 62
5.1
42 57 59 58 59 54 49 36
48 62
7.1
42 58 59 58 58 54 49 35
49 62
10.1 54 54 60 60 55 51 46 41 47 61
12.1
59 59 64 62 63 60 53 56
53 67
Sound levels refer to the unit at full load installed on the ceiling, ducted, with minimum, standard and maximum air flow rate of the fan.
Available static pressure 40 Pa.
In accordance with the UNI-EN ISO 3744 regulation, the average sound pressure level refers to a distance of 1 m from the outer surface
of a ducted unit installed on the ceiling.
Measurements are made in accordance to the UNI EN ISO 9614-2, with units installed over two sound reflective surfaces.
If the unit is installed in conditions other than the nominal ones (for instance, near walls or obstacles in generally) the sound levels may
undergo substantial variations.
