6
General Details
1.2 Description of system components
5
11
9
1
6
7
8
2
3
12
A
B
+
-
4
10
Fig. 1
A Air inlet
B Air outlet
1 Wall mounting plate
2 Indoor unit
3 Ventilation slit
4 Filter
5 Outdoor unit
6 Flexible drainage hose
7 Electrical connection
8 Refrigerant piping
9 Outdoor unit power supply
10 Remote control
11 Remote control support
12 Display LED SCHIARA 2
l
WARNING
The images in this manual are provided for illustrative purposes only. The appearance of your device may
dier slightly from the illustrations shown here. Refer to the actual characteristics of the unit.
