General Details
1.3 Accessories
The air conditioner is equipped with the following accessories. Use all specified installation components and accessories
to install it. Incorrect installation may cause water leakage, electric shock and fire, or cause the unit to malfunction.
Description Aspect Quantity
Gasket 1
Exhaust fitting 1
Installation use and maintenance
manual
1
Magnetic ring
(If supplied and packed with
accessories, refer to the wiring
diagram to install it on the connection
cable. )
Pass the strap
through the hole
in the magnetic
ring to secure it
to the cable
1
Connection pipe unit
Liquid side Ø 6.35 mm (1/4")
Components to be purchased
separately.
Consult your dealer for pipe sizes.
Gas side Ø 9.52 mm (3/8")
