SIZE 115.4 ÷ 130.4 EXC / 145.4 PRM
1. Internal exchanger (evaporator)
2. External exchanger (condenser)
3. Unit fixing holes
4. Lifting brackets (removable)
5. Electrical panel
6. Power input
7. Sound proof enclosure (optional)
8. Clearance access recommended
SIZE
115.4 EXC 130.4 EXC 145.4 PRM
ST SC/EN ST SC/EN ST SC/EN
Length mm 4175 4175 4175 4175 4175 4175
Depth mm 2228 2228 2228 2228 2228 2228
Height mm 2535 2535 2535 2535 2535 2535
W1 Supporting point kg 588 647 640 700 654 713
W2 Supporting point kg 542 607 577 642 619 684
W3 Supporting point kg 531 566 570 605 569 604
W4 Supporting point kg 485 525 507 547 534 575
Operating weight kg 2145 2345 2294 2494 2376 2576
Shipping weight kg 2115 2315 2254 2454 2336 2536
The presence of optional accessories may result in a substantial variation of the weights shown in the table.
DAAT40002_00
DATA/DATE 29/11/2020
