SIZE 170.5 ÷ 180.5 PRM
1. Internal exchanger (evaporator)
2. External exchanger (condenser)
3. Unit fixing holes
4. Lifting brackets (removable)
5. Electrical panel
6. Power input
7. Sound proof enclosure (optional)
8. Clearance access recommended
SIZE
170.5 PRM 185.5 PRM
ST SC/EN ST SC/EN
Length mm 4175 4175 4175 4175
Depth mm 2228 2228 2228 2228
Height mm 2535 2535 2535 2535
W1 Supporting point kg 741 806 777 841
W2 Supporting point kg 632 693 697 757
W3 Supporting point kg 649 689 672 712
W4 Supporting point kg 540 576 592 628
Operating weight kg 2563 2763 2738 2938
Shipping weight kg 2513 2713 2678 2878
The presence of optional accessories may result in a substantial variation of the weights shown in the table.
DAAT40003_00
DATA/DATE 19/03/2020
