Page #26 background imageLoading...
Page #26 background image
46 Series Installation and User Guide V1.0
26
Examples
1. Music source selection:
The values of x and y in the general format are the Line Input No. (1 to 6) and the Zone No. (1 to 4) respectively..
EXAMPLE COMMAND (ASCII) COMMAND (HEX)
Select Input 3 in Zone 2
<Z2.MU,S3/>
3C 5A 32 2E 4D 55 2C 53 33 2F 3E
2. Music levels:
Levels can either be set in a specied zone to an absolute value (in dBs), or increased/decreased by a specied number of dBs.
Either may be dened in steps of 1 dB.
For absolute levels, the number of dBs corresponds to attenuation rather than gain, thus 0 dB is maximum level and at -90 dB
the zone is muted. The values of y in the general format is the Zone No. (1 to 4) and m is the attenuation level in one-dB steps
(0 to 90) respectively.
To alter the zone level by a specied amount, the additional ASCII characters ‘U’ (up) or ‘D’ (down) are added to the string. The
values of y, p and q in the general format are the Zone No. (1 to 4), the level increase in one-dB steps (0 to 90), or the level
decrease in one-dB steps (0 to 90) respectively. A command to increment the level by a number of dBs greater than the current
attenuation will set the level to maximum. Similarly, a command that would decrement the level below 90 dB attenuation will
mute the Zone output.
.
EXAMPLE COMMAND (ASCII) COMMAND (HEX)
Set level in Zone 2 to -12 dB
<Z2.MU,L12/>
3C 5A 32 2E 4D 55 2C 4C 31 32 2F 3E
Reduce level in Zone 1 by 10 dB
<Z1.MU,LD10/>
3C 5A 31 2E 4D 55 2C 4C 44 31 30 2F 3E
Increase level in Zone 2 by 6 dB
<Z2.MU,LU6/>
3C 5A 32 2E 4D 55 2C 4C 55 36 2F 3E
3. Mute/Unmute Mics
The 46 Series mixer-amplier’s mic inputs may be individually enabled or disabled. This may be done on a per-zone basis or
globally (all zones). Note the character following ‘M’ may take the values ‘1’ (Mic 1), ‘2’ (Mic 2) or ‘I’ (both mics).
EXAMPLE COMMAND (ASCII) COMMAND (HEX)
Mute mic in Zone 2 only
<Z2.M1,M/>
3C 5A 32 2E 4D 31 2C 4D 2F 3E
Unmute mic in Zone 2 only
<Z2.M1,O/>
3C 5A 32 2E 4D 32 2C 4F 2F 3E
Mute both mic inputs globally
<MI,M/>
3C 4D 49 2C 4D 2F 3E
Unmute both mic inputs globally
<MI,O/>
3C 4D 49 2C 4F 2F 3E
