The table below lists the current taken by various Cloud options which may be
installed in the host mixer (gures are per item; those for EQ cards are per-channel):
Option Required Current
Active Remote Plates
LM-1 12 mA
DM-1 18 mA
AE-1 9 mA
BE-1 24 mA
LE-1 22 mA
ME-1 43 mA
DCM-1 Remote Control Plate
CDR-1(F) 50 mA
Bose® EQ Modules*
BEQ: M8, M32, MA12, 402, 502A, 802,
MB4, MB24, 502B, 502BEX
12 mA
BEQ: LT3202, LT4402, LT9402, LT9702 17 mA
BEQ: M16, DS100, DS16, M1B 34 mA
Amina EQ Modules*
EQ-AIWX 9 mA
EQ-LFIT 12 mA
Soundtube EQ modules*
RS4-EZ 12 mA
RS500i, RS400i 9 mA
RS100i 6 mA
The installer should check what options (if any) are tted, and de-rate the “Available
Current” gure accordingly before checking if the host has sufcient spare current
capacity to power the PM.
*Note that in the case of the DCM-1, tting loudspeaker EQ modules does not reduce the current
available from the host.
