PM4/8/12/16 & PM4/8-SA Installation and User Guide v1.1
24
Current considerations
The table below gives the current required by the various PM models:
PM Model Required Current
PM4 72 mA
PM8 83 mA
PM12 95 mA
PM16 107 mA
The following table shows spare DC current available from various Cloud host
mixers, etc., for powering additional items:
Host Available Current
DCM-1 650 mA
Z4
II 120 mA
Z8
II 190 mA
CX163 Use ext. PSU
CX263 Use ext. PSU
36/50 Use ext. PSU
46/50 80 mA
These gures apply to the host units without any active options installed, such as
internal loudspeaker EQ cards or remote plates. These options all consume power, so
the available current may be insufcient to power the PM. In such cases, an external
PSU must be used.
