PM4/8/12/16 & PM4/8-SA Installation and User Guide v1.1
52
Technical Specications
PM4/8/12/16 PM4-SA, PM8-SA
Microphone
Capsule Type Condenser
Polar Pattern Cardioid
Gooseneck length 300 mm (standard); 140 mm (alternative Part No. MI100166)
Zones Number of Zones 4, 8, 12 or 16 4 or 8
Chime Number of Chimes 4; internal speaker
4 or 8 (derived from media card);
internal speaker
Interface
Digital Cloud Digital Paging Interface (RJ45)
Analogue Zone Access Output (Short to Ground), Audio Output
Messages
Number of messages 4 or 8; internal speaker
Card format
SD/SDHC
MiniSD/SDHC*
MicroSD/SDHC*
Max. card size 2 GB (SD); 32 GB (SDHC)
File system FAT16 or FAT32
File types MP3 or WMA
Power input
Voltage range 9 - 17 VAC, 12 - 24 VDC
Current consump-
tion
72 mA (PM4)
83 mA (PM8)
95 mA (PM12)
107 mA (PM16)
120 mA (PM4-SA, idle mode)
220 mA (PM4-SA, message mode)
150 mA (PM8-SA, idle mode)
250 mA (PM8-SA, message mode)
Dimensions 245 wide x 65 high (less gooseneck mic) x 170 deep (mm)
Net Weight 1.2 kg
* Mini and Micro cards require a suitable adaptor.
