CM 653 Series - Repair Parts List

11 P/N 53855 (653-D) Rev AA May 2015
SERIES 653
ENGLISH
Part
Number
Drawing
Number
Description Qty.
653-0001 653 Gear Kit 0.75T & 1T
5 Gear Set (2 Gears) 1
7 Pinion 1
23 Lift Wheel Gear Kit 1
19 Brake Nut Kit 1
653-0002 653 Gear Kit 1.5T & 2T
5 Gear Set (2 Gears) 1
7 Pinion 1
23 Lift Wheel Gear Kit 1
19 Brake Nut Kit 1
653-0003 653 Gear Kit 3T & 6T
5 Gear Set (2 Gears) 1
7 Pinion 1
23 Lift Wheel Gear Kit 1
19 Brake Nut Kit 1
653-0010 653 Lift Wheel & Gear Kit 0.75T & 1T
22 Liftwheel 1
24 Liftwheel Roller Kit 1
19 Brake Nut Kit 1
653-0011 653 Lift Wheel & Gear Kit 1.5T & 2T
22 Liftwheel 1
24 Liftwheel Roller Kit 1
19 Brake Nut Kit 1
653-0012 653 Lift Wheel & Gear Kit 3T & 6T
22 Liftwheel 1
24 Liftwheel Roller Kit 1
19 Brake Nut Kit 1
653-0020 653 Side Plate Kit 0.75T & 1T
1 Side Plate Assembly (Gear Side) 1
2 Side Plate Assembly (Brake Side) 1
19 Brake Nut Kit 1
653-0021 653 Side Plate Kit 1.5T & 2T
1 Side Plate Assembly (Gear Side) 1
2 Side Plate Assembly (Brake Side) 1
19 Brake Nut Kit 1
653-0022 653 Side Plate Kit 3T & 6T
1 Side Plate Assembly (Gear Side) 1
2 Side Plate Assembly (Brake Side) 1
19 Brake Nut Kit 1
Part
Number
Drawing
Number
Description Qty.
653-0030 653 Stripper Kit 0.75T & 1T
10 Chain Guide Roller 2
4 Stripper 1
19 Brake Nut Kit 1
653-0031 653 Stripper Kit 1.5T & 2T
10 Chain Guide Roller 2
4 Stripper 1
19 Brake Nut Kit 1
653-0032 653 Stripper Kit 3T & 6T
10 Chain Guide Roller 2
4 Stripper 1
19 Brake Nut Kit 1
653-0050 653 Handle Kit 0.75T
16 Lever Handle Assembly 1
15 Lever Hardware Kit 1
31 Name Plate Kit 1
21 Lever Grip 1
19 Brake Nut Kit 1
653-0051 653 Handle Kit 1T
16 Lever Handle Assembly 1
15 Lever Hardware Kit 1
31 Name Plate Kit 1
21 Lever Grip 1
19 Brake Nut Kit 1
653-0052 653 Handle Kit 1.5T
16 Lever Handle Assembly 1
15 Lever Hardware Kit 1
31 Name Plate Kit 1
21 Lever Grip 1
19 Brake Nut Kit 1
653-0053 653 Handle Kit 2T
16 Lever Handle Assembly 1
15 Lever Hardware Kit 1
31 Name Plate Kit 1
21 Lever Grip 1
19 Brake Nut Kit 1
CM 653 HAND OPERATED LEVER HOIST
REPAIR PARTS LIST
Please provide the following information:
- Model number
- Serial number
- Part description and number as shown in parts list
