MAN. 126 rev.4 Use and maintenance manual S19
19 of 77
Picture 13: automatic stabilization control station (basket)
Through basket station is equally possible to carry out the automatic
stabilization/destabilization automatic through the SSAC buttons.
3.4
Crawlers handling control station
Picture 14: translation control station (radiocontrol )
The radiocontrol on the side has a green “link” (small key)
which starts the connection between the receiver and the radio and
activates the emergencies once the machine is electrically fed.
SSAC
J1
J2
TS
LT
