MAN. 126 rev.4 Use and maintenance manual S19 31 of 77
In case such conditions are not met, it is strictly
forbidden to use the MEWP.
6. Place the MEWP on the chosen area;
7. Define the work station area with appropriate signage
(white-red ribbon, white-red chains, cones etc.).
4.4.2 

 MEWP stabilization
8. Lift the 4 pins blocking the stabilizers position. If this operation
proves difficult, move the stabilizer trying to rotate it as to the
horizontal plane during the lifting. It is absolutely forbidden – and
unnecessary – to completely remove the pins from their seat.
Picture 25: stabilizers pin
9. With the pin lifted, rotate the stabilizer taking it in a position which
allows the re-insertion of the same pin. For each stabilizer, it will
be possible to choose two positions: the positions taken by the
stabilizers will allow or stop the mechanical block of the bearing
rotation and thus of all the aerial part of the spider.
