17
5 Installation Guide
5.1 Power Supply
1. Make sure the power switch is set to OFF.
2. Connect the AC adaptor to the POWER IN port in the rear panel.
3. Make sure the AC requirement of the AC adaptor is compliant with the local AC
supply, then connect the AC adaptor to the power supply outlet.
Make sure the AC requirement of the AC adaptor is compliant with the local
AC supply, otherwise it will cause severe damage to the AC adaptor or the
instrument, and it may cause electrical shock!
Only the AC adaptor that goes with the VX should be used. If you cannot find
the VX AC adaptor or the adaptor does not work, please contact local CME
dealers.
The VX AC adaptor varies from country to country. If you take your VX from
one country to another, please make sure your AC adaptor compliant with the
local power supply.
5.2 Power On In Proper Order
When you have your VX connected to a system, please set all the volume to minimum
then follow the proper order to turn all the devices on: master MIDI device (which sends
out MIDI data), slave MIDI device (which receives MIDI data), audio devices (mixer,
amplifier, speakers). When you follow this order, all the signals (MIDI and audio) will go
properly from the beginning to the end. If you will turn off the system, please follow the
reverse order (turn off audio devices first, then MIDI devices).
5.3 Connections
Before you make these connections, please turn off all devices to avoid
possible damage.
The headphone and LINE OUT of VX are used for the computer signal other
than for the expansion board. If VX is not connected to the computer, LINE
OUT and MIC/LINE IN do not work.
Please refer to the fig. below to make connections:
To Next Page
