28
8.3.2.2 Auto-display For Drum Pads
z The velocity-sensitive pads will send specific MIDI messages to the designate MIDI
port/channel.
z Auto-display for pads is shown as below:
P a d : 0 1
N o t e : 0 0 1 ( C # - 2 )
Pad means pad#01-12.
Note indicates the note# and name, the note# range is 000-127.
In the favorite folder mode, you cannot change port/channel or change the pad
function from note to controller, however, you can to it in the Assigning mode.
Press an F-button for the F1-F8 display. If you press the current working
F-button, it will not send the voice messages, otherwise it will send
corresponded voice messages.
Note: if pads function is controller instead of note, the displayed content will be
different than showed above.
8.3.2.3 Auto-display For SEQ Transportation Buttons
z The SEQ transportation buttons will send specific MIDI messages to the designate
MIDI port/channel.
z The keyboard indicator LED display may differ from the indicators in the computer
software, in that case please use the indicators in the computer software.
z In the F1-F8 mode, after pressing the SEQ buttons and auto-display works, you
cannot assign the button functions. To do so, please enter the ASSIGNing mode.
z Auto-display for the 6 SEQ buttons is shown below:
S T O P
T e m p o : 1 2 0
As you press the 6 SEQ buttons, the display will change accordingly to: Return
to Zero(RTZ), Rewind(REW), Fast forward(FF), Record(REC), Stop(STOP) and
Play(PLAY).
Tempo is the song tempo, default value is 120, range is 20-250.
Press an F-button for the F1-F8 display. If you press the current working
F-button, it will not send the voice messages, otherwise it will send
corresponded voice messages.
8.3.2.4 Auto-display For Octave / Transpose
z The Transpose function will change the keyboard pitch by semi-notes.
z The Octave function will change the keyboard pitch by octaves.
z The VX 50/60/70/80 default keyboard range is shown below:
