CNC 6040 Router / Engraver System
CNCDIY CNC Routing Machines System User’s Manual
14
Spanner
The nuts and crank bolts installation
Hammer
(Plastic)
The small adjustment and part assemble!
B. Electrical Parts
Tools Name Description Picture
Soldering
iron
To melt the solder for wire connection.
The best power range is between 30W~
60W.
Soldering Tin
To melt to join wire cable
Power Cable
300/300V
1. 4 wires Cable
Model RVV4*1
Length: 5.9m (19.4ft)
2 wires Cable
Model RVV2*1
Length: 3.1m (10.2ft)
Heat-
Shrinkable
plastic
To protect the wire’s join
The recommended sizes are 3mm and 5mm
Spiral
Wrappings
To protect the cable
The recommended inside diameter are 5mm
and 8mm
