CNC 6040 Router / Engraver System
CNCDIY CNC Routing Machines System User’s Manual
7
Chapter 3 Hardware Installation
3-1 Installation Precaution
The CNC Routing Machine system contains numerous delicate electronic circuits and
components which can become damaged. Prior to installation, carefully read the user’s manual
and follow these procedures:
z When connecting hardware components to the connectors of the Control system, make sure
they are connected tightly and securely.
z Before using the product, please verify that all cables and power connectors of your
hardware components are connected
z Before unplugging the power, make sure the power supply voltage has been set according to
the local voltage standard.
z Do not place the machine system on an uneven surface.
z Do not place the machine system in a high-temperature environment.
z Turning on the control system power during the installation process can lead to damage to
system components as well as physical harm to the user.
z If you are uncertain about any installation steps or have a problem related to the use of the
product, please consult a certified computer technician.
z The main material of the routing machine is used aluminum alloy, cannot be used due to
any inadvertently fall or collision to damage the machine. Please placed the routing
machine system in a firm, stable, level of desktop, thin desktop will result in a greater
resonance in the noise during the machine running.
z Electric control box is installed well with a switching power supply, a stepper drive
controller and a spindle power driver. Please place it in the level of ventilation. Electric
control box cannot have electromagnetic interference within around 10 meters. Please also
care about wrestling and fear flows effect!
z Remember to tidy up the wiring harness, messy take place. It is likely to impede the normal
movement of the routing machine. Please consider the stroke area for the moving gantry
and any sliding part with sufficient margin of the wiring harness.
