3-10 Basic Testing with CNC Control Box
Step 1 Interconnection Check
This is a preliminary test to confirm the interconnection between the CNC control box and the
engraving machine. Therefore, all axes of the machine and the spindle (D57/C57) can be
controlled by the CNC control box properly.
Step 2 Switching off all of the driver power
First of all, please switch off both of the spindle power and the driver power switches (switch on
the "○" is off, "|" is opened), the spindle speed control knob transferred to "Safe Place" position.
The Emergency Stop button must be released. (Please refer to the related CNC control box user’s
manual)
Step 3 Turning the knobs of each axis during power off
Now, user turns the knob of X-axis by hand twist to feel the axis whether locked by the particular
stepping motor or freedom to turn!
If it is Locked = Problem
If the axis was locked before switching on the driver power, please find the cause of this
problem. (i.e. Check the steeping motor moving part) If the problem cannot be solved,
please contact us asap!
If it is freedom to turning = Normal
Please check another axis with the same method!
Step 4 Turning the knobs of each axis during power on
User switches on the driver power and turns the knob of X-axis by hand twist to feel the axis
whether locked by the particular stepping motor or freedom to turn again!
If it is Locked = Normal
If the axis was locked before switching on the driver power, this is a normal. Please check
another axis with the same method!
If it is freedom to turning = Problem
If the axis was unlocked after switching on the driver power, please find the cause of this
problem. (i.e. Check the connection, Check the steeping motor moving part) If the problem
cannot be solved, please contact us asap!
