Settings
98-135323-H Chapter 2: Operation 19
Dynamic Data (read only)
The dynamic data is provided by the ship’s sensors.
Extended Stern
c, d
Towing Extension to stern in m.dm (transmitted in
meters).
Extended Port
c, d
Towing Extension to port side in m.dm (transmitted in
meters).
Extended Starboard
c,
d
Towing Extension to starboard side in m.dm
(transmitted in meters).
a. Visible if Inland Waterways is disabled.
b. Visible if Inland Waterways is enabled, see also Figure 18 on page 24.
c. Visible if Status is set to "Power-Driven Vessel Towing Alongside", see also
Figure 18 on page 24.
d. When setting more than one extended dimension, the AIS will transmit
message 5 with incomplete information for every entry, until the last
dimension is set.
Item Description
Figure 15: Settings – Dynamic data (read only)
