Service and repair
60 Chapter 3: Service & maintenance 98-135323-H
Applicable SAILOR and part numbers
This manual is for the SAILOR 6280/6281 AIS System and is applicable to the
part numbers below:
Accessories
The following accessories are included in the delivery:
Replacing the fuse
One fuse is installed in the SAILOR 6282 AIS Transponder. If this fuse is blown,
do as follows:
1. Track down why the fuse was blown and solve the problem.
2. Take out the old fuse. Use the fuse puller.
3. Insert the new fuse. The fuse rating is 5 A T.
Part number Description
406282A SAILOR 6282 AIS Transponder
406004A SAILOR 6004 Control Panel
406285A SAILOR 6285 GNSS Antenna - Active
406283A SAILOR 6283 AIS Connection Box and Wall Tray
Part number Description accessories
37-130130 DC Power cable for SAILOR 6282 AIS Transponder and
SAILOR 6004 Control Panel
37-135955 SUB-D50 cable, 1 m
37-207073-000 RJ45 Cat5e STP LAN cable, 5 m
41-135855 GPS Antenna bracket
67-135974 Pilot plug
